| Engine |
| Engine Model |
4D33 |
| Engine Type |
4 Cylinders in–line side cam |
| Fuel System |
Diesel, Direct Injection |
| Compression ratio |
18 |
| Valve mechanism |
Overhead valves |
| Bore × stroke mm |
φ108 × 115 |
| Displacement (cc) |
4214 cc |
| Max. Power (PS @ rpm) |
120 / 3,200 |
| Max. torque (N.M @ rpm) |
304 / 1,800 |
| Performance |
| Max Speed (Km/h) |
120 km/h |
| Gradeability |
38.00% |
| Min. Turning radius (m) |
6.8 m |
| Transmission |
| Model |
M035S5 |
| Type |
5 forward + 1 Reverse |
| Tires |
| Tire Size |
7.5R16 |
| No. of Wheels |
6 + 1 spare tire carrier |
| Steering |
| Type |
Left hand side |
| Operation |
Ball and nut with integral hydraulic power booster |
| Suspension |
| Front |
Laminated leaf spring with shock absorbers |
| Rear |
Laminated leaf spring with shock absorbers |
| Brakes |
| Service |
Hydraulic with vacuum servo assistance, dual circuit |
| Parking |
Internal expanding type on propeller shaft |
| Engine |
Exhaust Brake |
| Dimensions |
| Minibus length |
7,630 mm |
| Width |
2,230 mm |
| Overall, Height |
2,760 mm (Without Ac) |
| Saloon Height (at center) |
1,900 mm |
| Wheelbase |
3.850mm |
| Height of first step |
350 mm |
| Bodywork |
| Structure design (Flat Platform for Passenger Seats) based on the principle of distribution of strengths and materials resistance, adapted to chassis features |
| Interior Side finish: |
| Formica 3 mm thickness |
| Color : Light Gray RAL 7001 |
| Roof finish: |
| -Interior trim Complete, saloon illumination |
| -Ply wood covered with Velvet |
| -Color: Light blue |
| Exterior finish: |
| Exterior side paneling galvanized steel, 1mm thickness |
| Exterior roof paneling GRP, 3mm thickness |
| Front and rear end made of molded fiberglass (GRP – Glass Reinforced Polyester) |
| Front and rear bumper made of molded fiberglass (GRP – Glass Reinforced Polyester), |
| Painting with White color |
| Engine compartment: |
| Fire resistant sound and heat insulation in three layers |
| Sound absorption |
| Thermal insulation |
| Floors: |
| Flooring Surface treated plywood 12mm |
| Floor covering Nonslip type PVC 3mm |
| Doors: |
| Driver Door LHS Front Manually operated out swing |
| Courier Door RHS Front Manually operated out swing |
| Middle Passengers RHS: |
| oFoldable |
| oElectrically operated (Can be opened manually from inside on emergency) |
| oWidth / height: 650 / 2020 mm |
| oWith reverse function |
| Bumpers: |
| Material: fiber glass (GRP) |
| Thickness: 3-5 mm |
| Windshield: |
| Front windshield double glass & UV protection 0 – 1 % |
| Laminated L.S.G. (2 parts, white) Bonded |
| Electric windshield wiper |
| Windows: |
| Bonded side glazing |
| Opening Window according to Layout |
| Water Clear Side window glass |
| One piece tempered rear window |
| Breakable windows used as emergency exit |
| Safety hammers |
| Driver Seats: |
| Seat with 3-point safety belt and Mechanical suspension adjustment |
| With Arm rest |
| Passengers Seats: |
| 27 + Courier + Driver Fixed Back Seat Covered with fabric – Mini |
| With Arm rests on the Aisle side |
| Double Seat width 800 mm |
| Cushion height 450 mm |
| Aisle Width 350 mm |
| 2P Seats belts (3P up on request) |
| Dashboard: |
| Ergonomically designed with full controls, Semi-Rigid PU |
| Mitsubishi standard instrument panel |
| Android Monitor 7” + USB + Rear view Camera |
| Storage: |
| Side and rear 2 m3 |
| Air conditioner: |
| Thermo King X500 |
| Cooling Capacity 18 Kw |
| Refrigerant R134a |
| Fuel Tank: |
| 100 Liters |
